WIRING DEVICE-KELLEMS
LKG PLG, 30A 250V, HUB PRO, L6-30P
Locking Devices, SELECT SPEC Twist-Lock®, Commercial/Industrial, Male Plug, 30A 250V, 2-Pole 3-Wire Grounding, L6- 30P, Screw Terminal, Black
| UNSPSC | 39121402 |
|---|---|
| UNSPSC Category | Electrical plugs |
| Package Description | Stnd Pack of - 10 |
| Package Type | PK |
| Package Quantity | 1.0 |
| Manufacturer | Hubbell |
| Manufacturer Item Status | Active |
| Application | Industrial/Commercial |
| Material | Composite |
| Wire Size | #12 AWG to #8 AWG |
| Phase | 1 |
| NEMA Rating | L6-30P |
- Visible NEMA ratings
- Captive assembly screws
- Supertough® nylon body
- Impact modified nylon blade/contact holder
- Brass contacts/blade
- Withstands 3500 VAC per UL 498 dielectric voltage
- 600 VAC or 250 VDC maximum working voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL 498
- Minimum 4.8 times rated current for 100 cycles overload
- Terminals identified in accordance with UL 498 (brass, white, green)
- 18 to 8 AWG flexible cord
- Ratings and NEMA identification are permanently marked on device
- Indoor dry unless protected by additional means
- 10 to 8 AWG wire
